DATA LINK SIMULATOR

RDS-PLUS는 시간 지연 및 비트 오류와 관련하여 물리적 네트워크 동작을 현실적으로 시뮬레이션하는 모듈식 네트워크 링크 오류 및 지연 시뮬레이터입니다. RDS-PLUS는 1200bps에서 50Mbps 이상에 이르는 광범위한 인터페이스 유형과 속도를 지원합니다.

SPECIFICATION

Application	WAN Delay Emulator for interconnection of two devices, (e.g. terminal, modem, or other network or CPE with standard serial digital interfaces) located within proximity of each other while simulating clock generation, network delays, random and burst errors, and BERT capability
Simulation Delay Times	5 milliseconds(mS) to over 4000 mS, in 1 mS increments, or from 4 bits to over 65,000 bits in 1 bit increments. 4 seconds each data path, 8 seconds round trip delays.
Capacity	Two (2) data port interfaces
Data Rates	From 1.2K to 51.84Mbps
Data Port Interfaces	Available in EIA-644(LVDS), RS-232, RS-422/449, RS-530, V.35, X.21, TTL, HSSI, DS1/E1, DS3, E3, STS-1
Clock Sources	Internal, Stratum 4 or Locked to External, Data Port RX/TX supplied
Data Format	Synchronous or Asynchronous
Delay Units	Specified in milliseconds or in bits
Random Error Rates	From 1x10-1 to 1x10-12
Burst Errors	Burst duration from 1mS to 4 SecondsOff-interval from 1mS to 16 Seconds
Test Modes	Loopback, 511 BERT
Operator Console	RS-232 Async, 38.4kbs, (HyperTerminal recommended)*Optional web enabled GUI interface
Indicators	Power TXD, RXD, TXC, RXC, RTS, CTS, DSR/DTR, DCD for each user port
Power Source	90-240VAC @10%, 50/60Hz, IEC Power Inlet, (2) 5mm Fuses
Dimensions	Height: 1.75 inches (4.44 cm),Width: 17 inches (43.18 cm),Length: 9 inches (22.86 cm)
Weight	4.5 pounds (2.1 Kg)
Regulatory Approvals	UL 60950-1:2003, CAN/CSA-C22.2 No. 60950- 1:2003, FCC Part 15, EN55022:2006, ICES-003, Class A

APPLICATION
