FEATURES
SPECIFICATION
Any To Any Port |
Network: Ten (10) SR or LR Network Taps with Dual LC connectors Monitoring: Two (2) SR or LR Monitoring Ports Management Port: RJ45 Console Port: DB9 |
Split Ratio | 50/50, 70/30, 80/20 (Additional Split Ratios Available) |
Insertion Loss* |
Multimode (choose 50/62.5 micron diameter) 50/50 = 4.2 dB Multimode (choose 50/62.5 micron diameter) 70/30 = 3.0 / 6.7 dB Singlemode (9 micron diameter) 50/50 = 3.9 dB Singlemode (9 micron diameter) 70/30 = 2.2 / 6.3 dB * typical per fiber |
Power Requirements |
Dual Redundant Hot Swappable Power Supplies (Included) Maximum Power Consumption: Less than 200 Watts Individual Power Supply Rating: 100-240V ~47-63Hz 4A MAX |
Certifications | CE, RoHS |
Dimensions (H x W x D) | 1.72 x 19.00 x 26.5 in (4.37 x 48.26 x 67.31 cm) |
Weight | 18.15 lbs (8.23 kgs) |
Environmental |
Operating Temperature: 32º to 104ºF (0º to 40ºC) Storage Temperature: -22º to 149ºF (-30º to 65ºC) Humidity: 5 to 90% non-condensing |
Warranty | One (1) Year Hardware Warranty included, Advanced Replacement-Next Day, 3rd Business Day options available |
ORDERING INFORMATION
Product | Description |
SS-2212-10G |
SINGLEstream 10G Link Network Tap (10-Taps, 2 Non-Aggregated Monitoring Ports) |
Model Options |
SR: multi-mode (50 or 62.5 micron) LR: single-mode (9 micron) |
Rack Mount Ears included |
